Milling Machine Vertical Turret Series Horizontal Series Vertical & Horizontal Series Bed Type Series Heavy Cutting Series CNC Column Machine TMA Series TMB Series TMC Series TMD Series TME Series Lathe High Effective Series High Precision Series Heavy Duty Lathe Drilling/Tapping Machine Radial Drilling Series Drilling Machine Series Tapping Machine Series Boring Machine Horiznotal Boring Series Grinding Machine Saddle Type Column Type Cantilever Type Double Column Type High Precision Surface Super Precision Surface Rotary Type Band Saw Vertical Type Horizontal Type Column Type EDM NC EDM Double Head EDM   Drilling Machine   Specification Unit TG-13 TG-16A TG-16B TG-20 TG-25A TG-25B Main Spindle Spindle speed rpm 520~2230 630~2700 240~2840 290~3440 470~1730 570~2100 230~1910 270~2290 255~2020 310~2450 230~1910 270~2290 Number of spindle speeds steps 4 9 4 9 6 9 Spindle taper   JT6 MT2 MT3 Quill travel mm 80 100 120 140 Distance from spindle to table surface mm 450 400 720 630 630 Distance from spindle to base surface mm 620 600 920 930 Distance from spindle center to column center mm 180 230 Capacity Diameter of column mm Ø80 Ø92 Ø102 Diameter of Table mm Ø360 Ø320 Ø400 Ø420 Dimension of base mm 300×500 335×580 380×600 Drilling steel capacity mm Ø13 Ø16 Ø20 Ø25 Motor Main spindle HP 1/2 1 2 Size & Weight Machine height mm 300×500×1070 300×500×1050 335×580×1500 380×600×1600 380×600×1540 Machine weight kg 75 90 100 140 220 190       Specification Unit TGZ-13 TG-20 Main Spindle Spindle speed rpm 2500, 3400, 4200, 3000, 4000, 5000 830, 1670, 2500. 1000, 2000, 3000 Number of spindle speeds steps 3 Spindle taper   JT2/ER20 JT6/ER20 Quill travel mm 60 100 Distance from spindle to table surface mm 400 Distance from spindle to base surface mm 600 Distance from spindle center to column center mm Ø360 Ø400 Capacity Diameter of column mm Ø80 Diameter of Table mm Ø320 Dimension of base mm 330×510 300×510 Drilling Al capacity mm Ø6 Ø10 Stabilizer Travel mm 25 50 Pneumatic Power kg/mm² 500~700 Motor Main spindle HP 0.5 1 Size & Weight Machine height mm 1350 Machine weight kg 100
